Azenta 7.6ml Tri-Coded Tubes, Screw Caps, 24-format, Bulk, External Thread, 240 Tubes
Item #T39-542 Mfg #65-9303
The Azenta Life Sciences 7.6 mL Tri-Coded Tube, 24-Format, External Thread is designed for secure storage, identification, and tracking of larger-volume samples in biobanking, compound management, and other laboratory sample storage applications.
Each tube incorporates three matched identification methods: a permanent 2D code laser etched on the base, a 1D linear barcode on the side, and a corresponding human-readable number. The 24-format external-thread design provides increased working volume while remaining compatible with automated barcode reading, capping, decapping, and sample management workflows.
Technical Features
- 24-format external-thread sample storage tube
- Manufactured from high-quality virgin polypropylene
- Permanent 2D code laser etched on the tube base
- Matching 1D linear barcode and human-readable number laser etched on the tube side
- All three identification codes are matched for sample traceability
- 2D code can be read without removing the tube from the rack
- High-contrast coding supports reliable reading under frost or condensation conditions
- Each tube is quality controlled for code readability and uniqueness
- Leak tested for sample security
- External-thread design provides greater usable volume than comparable internal-thread designs
- Compatible with automation-friendly screw caps
- Double-start screw-cap thread engages within a maximum 180° rotation
- Suitable for cryogenic storage down to -196°C
- Designed for compatibility with automated barcode readers, capping systems, and sample management platforms
Specifications
- Maximum Working Volume: 7.6 mL
- Maximum Fill Volume at 21 degrees C: 7.2 mL
- Tube Format: 24-format
- Thread Type: External
- Coding: 2D code on base
- Tube Height: 77.4 mm
- Tube Height with Cap: 83.6 mm
- Inner Diameter: 13.0 mm
- Outer Diameter with Cap: 17.0 mm
- Center-to-Center Spacing: 18.0 mm
- Minimum Storage Temperature: -196°C
- Tube Height in Rack: 84.7 mm
more
$829.00
